- Supports Intel® Xeon® E3 v5 or 6th-Gen Core ™ i7 / i5 LGA1151 CPU
- Supports NVIDIA® GPU (up to 250W TDP)
- Patented thermal design for -25 ° C to 60 ° C rugged operation *
- Two x8, Gen3 PCIe slots for add-on cards
- Dual GbE ports and four USB3.0 ports
- Three 2.5 "SATA hard drives with 0 RAID / 1 / 5 support
- Patented easy-swap trays * for HDD replacement
- Automatic temperature sensing and fan control
- Patented damping brackets * to withstand 1 Grms vibration
- Built-in ignition control
Nuvo-6108GC-IGN is one of the world's first industrial-grade in-vehicle GPU computing platforms supporting high-end graphics cards. It is designed to fuel emerging GPU-ccelerated applications, such as artificial intelligence, VR, autonomous driving and CUDA computing by accommodating 250W NVIDIA® GPU.
Leveraging Intel® C236 chipset, Nuvo-6108GC-IGN in-vehicle GPU computer supports Xeon® E3 v5 or 6th-Gen Core ™ i7 / i5 CPU with up to 32 GB ECC / non-ECC DDR4 memory. It incorporates general computer I / O like Gigabit Ethernet, USB3.0 and serial ports. In addition to the x16 PCIe port for GPU installation, Nuvo-6108GC series also has two x8 PCIe slots so you can install additional high performance expansion card with high bandwidths for data collections / analytics and communication.
Nuvo-6108GC-IGN comes with sophisticated power design to handle heavy power consumption and power transient of a 250W GPU. Moreover, to have reliable GPU performance for industrial environments, Nuvo-6108GC series uses Neousys' patented design *, the tuned cold air intake to effectively dissipate the heat generated by GPU. This unique design guarantees operation at 60 ° C under 100% GPU loading, making Nuvo-6108GC series extremely reliable for demanding field (such as in-vehicle condition) applications.
The new Nuvo-6108GC-IGN in-vehicle GPU computer features built-in ignition power control and two of its three 2.5 "drives come with Neousys' patented easy-swap trays for simple HDD / SSD replacement
Product Highlights
Wide-temperature GPU Computing Platform
Nuvo-6108GC-IGN supporting 250W nVidia® GPU & features wide-temp operation from -25 ° C to 60 ° C under 100% GPU load.
Award Winning Design
Winner of Vision Systems Design 2018 Innovators Award Program and Best Choice Award 2018
Specification
| System Core | |
|---|---|
| Processor | Supports Intel® Xeon® E3 V5 and 6th-Gen Core ™ LGA 1151 CPU -Intel® Xeon® Processor E3-1275 v5 (8M Cache, 3.6 / 4.0 GHz) * -Intel® Xeon® Processor E3-1268L v5 (8M Cache, 2.4 / 3.4 GHz) -Intel® Core ™ i7-6700 (8M Cache, 3.4 / 4.0 GHz) * -Intel® Core ™ i5-6500 (6M Cache, 3.2 / 3.6 GHz) * -Intel® Core ™ i7-6700TE (8M Cache, 2.4 / 3.4 GHz) -Intel® Core ™ i5-6500TE (6M Cache, 2.3 / 3.3 GHz) |
| Memory | Up to 32 GB ECC / non-ECC DDR4-2133 |
| Graphics | Independent GPU via x16 PEG port, or integrated Intel® HD 530 controller |
| chipset | Intel® C236 Platform Controller Hub |
| I / O interface | |
|---|---|
| Ethernet | 1x Gigabit Ethernet port by Intel I219-LM 1x Gigabit Ethernet port by Intel I210-IT |
| Native Video Port | 2x DVI-D connectors for DVI outputs, supporting 1920x1200 resolution |
| Serial Port | 2x Software-programmable RS-232 / 422 / 485 ports |
| USB | 4x USB 3.0 ports |
| Audio | 1x Speaker-out |
| Expansion Bus / Internal I / O Interface | |
|---|---|
| PCI Express | 1x PCIe x16 slot @ Gen3, 16-lanes PCIE signals for GPU 2x PCIe x8 slot @ Gen3, 4-lanes PCIE signals |
| M.2 | 1x M.2 B key socket for 3G / 4G options with SIM socket |
| mini-PCIe | 1x full-size mini PCI express socket |
| Remote Ctrl. & Status Output | 1x 2x6-pin 2.0mm pin-header connector for remote on / off control and status LED output |
| Storage Interface | |
|---|---|
| SATA | 2x easy-swap HDD trays for 2.5 "HDD / SSD installation 1x Internal SATA port for 2.5 "HDD / SSD installation, supporting RAID 0 / 1 / 5 |
| Power Supply | |
|---|---|
| DC Input | 24 VDC |
| Input Connector | 3-pin pluggable terminal block for DC input (IGN / GND / V +) |
| Mechanical | |
|---|---|
| Size | 178 mm (W) x 360 mm (D) x 174 mm (H) |
| Weight | 4.7 kg (incl CPU, GPU, memory and HDD) |
| Mounting | Wall-mounting with damping brackets |
| Environmental | |
|---|---|
| Operating Temperature | -25 ° C ~ 60 ° C with 100% CPU / GPU loading * / ** |
| Storage Temperature | -40 ° C ~ 85 ° C |
| Humidity | 10% ~ 90%, non-condensing |
| Vibration | Operating, 1 Grms, 5-500 Hz, 3 Axes (w / GPU, fan and HDD), according to IEC60068-2-64) |
| Shock | - |
| EMC | CE / FCC Class A, according to EN 55022, EN 55024 & EN 55032 |
Ordering Information
Nuvo-6108GC-IGN
Industrial-grade GPU computing platform supporting up to 250W NVIDIA® GPU Card, Intel® Xeon® E3 v5 and 6th-Gen Core ™ processor with built-in ignition control and 2x easy-swap trays
Accessories
PA-280W-OW
280W AC / DC power adapter 24V / 11.67A; 16AWG / 100cm; Cord end terminals for terminal block, operating temperature: -30 to 60 ° C
PA-480W-DIN
480W AC-DC power adapter DIN-rail mount, 24V 20A, 90 ~ 264VAC / 127 ~ 370VDC, terminal block, -20 to70 ° C, Meanwell SDR-480-24
